background image

28

F

+

+

FORCE:
Adjusts Motor thrust.

= minimum force
= maximum force

OPENING DIRECTION:
Indicates the gate opening movement and
makes it possible not to change the motor
connections on the terminal board.

= Rightward opening movement
= Leftward opening movement

STATUS OF AUTOMATED SYSTEM:
Exit from programming, save data, and return
to gate status viewing.

= Closed
= Now opening
= At "STOP"
= Open
= Pause
= "FAIL SAFE" tripped
= Now closing
= Now reversing
= Photocells tripped

Display

Function

Default

Display

Function

Default

Display

Function

Default

5.5.2.

ADVANCED PROGRAMMING

To access ADVANCED PROGRAMMING, press key F and, as you hold
it down, press key +:

•if you release key + , the display indicates the name of the first

function.

•if you release key F too, the display shows the value of the

function that can be modified with keys + and -.

•if you press key F (and hold it down), the display shows the

name of the next function, and if you release it, the value that
can be modified with keys + and - is shown.

•when you reach the last function, press F to exit the program,

and the display resumes showing the gate status.

The following table shows the sequence of functions accessible in
ADVANCED PROGRAMMING:

ADVANCED PROGRAMMING

MAXIMUM TORQUE AT INITIAL THRUST:
The motor operate at maximum torque (ignoring
the torque setting) at start of movement. Useful
for heavy leaves.

= Active

= Disabled

FINAL BRAKING:
When the gate engages the opening or
closing limit-switch, a braking stroke can be
selected to ensure the leaf is stopped
immediately. If decelerations are selected,
braking starts when they finish.
At

value, braking is disabled.

Time can be adjusted from

to

in

0.01-second steps.

= Braking disabled

from

to

= Timed braking

FAIL SAFE:
If this function is activated, it enables a function
test of the photocells before any gate
movement. If the test fails (photocells not
serviceable signalled by value

on the

display), the gate does not start moving.

= Active

= Disabled

PRE-FLASHING (5 s):
Activates the flashing lamp for 5 seconds before
start of movement.

= Disabled
= Only before opening

= Only before closing

= Before every movement

CLOSING PHOTOCELLS LOGIC:
Select the tripping mode of the closing
photocells.
They operate for the closing movement only:
they stop movement and reverse it when they
are released, or they reverse it immediately.

= Reverse on release

= Reverse immediately to opening

INDICATOR-LIGHT:

If

is selected, the output functions as a

standard indicator-light (lighted at opening
and pause, flashing at closing, and off when
gate closed).
Courtesy light: Different figures correspond
to timed activation of the output, which can
be used (by a relay) to power a courtesy
lamp. Time can be adjusted from

to

sec. in 1-second steps, and from

to

min. in 10-second steps.
Electric lock command and 'traffic lights'
functions:
If you press key - from the

setting, the

command for the

closing electric lock is

activated;
If you press - again, the command for the

closing and opening electric lock is set;

if you press the - key again, you can set the
'traffic lights' functions

and

.

= Standard indicator-light

from

to

= Timed output.

= electric lock command before opening

movement

= electric lock command before

opening and closing movements

= 'traffic lights' function: the output is

active in "open" and "open on pause" status
and is disabled 3 seconds before the closing
manoeuvre starts.
Note: there is 3 seconds of pre-flashing before
the closing manoeuvre.

= 'traffic lights' function: the output is

active only in "closed" status.
Attention: do not exceed the output's
maximum load (24Vdc-3W). If necessary,
use a relay and a power supply source
outside the equipment.
