CTI Products NCB/AY with Serial Interface User Manual
Page 49
CTI Products, Inc.
NCB-AY User Guide
Appendix E. Specifications
43
A
PPENDIX
E.
S
PECIFICATIONS
NCB Unit
DC Power Input:
10 to 30 VDC, Negative Ground, Externally Current Limited
5 watts maximum without SMX transceiver
10 watts maximum with SMX power line transceiver
Size:
7.5” D x 5.6” W x 1.6” H
Operating Temperature:
0 to 60
C
Humidity:
10-95% non-condensing
Mounting:
Desktop with integral non-slip feet
Wallmount or 19” rack mount with optional adapters
Transceivers supported:
FTT-10A, TPT/XF-78, TPT/SF-1250, SMX
Serial Ports:
2 Ports, one or two modems or adapters may be connected
1200 to 115200 bps
8 data bits, 1 stop bit, no parity
Maximum packet size:
66 bytes (factory default router configuration)
255 bytes (maximum with software re-configuration)
Dialing:
Modem Controller and Telephone Directory,
SNVTs or Explicit messages
Configuration:
Factory default router mode is set to Repeater. Configured or Bridge mode
set using standard LonWorks network management tools capable of
configuring routers.
Installation:
Can be done with Standard Network Tools
