Your Presentation Switcher / Scaler
6
Table 1: Front Panel Presentation Switcher / Scaler Features
# Feature Function
1 POWER Switch Illuminated switch for turning the machine ON or OFF
2 IR Receiver / LED Red when the unit accepts IR remote commands
3 UNIVERSAL INPUT Selector
Buttons
Press to select the composite video / s-Video / component video
source 1 (from 1 to 4)
4 UXGA 1 Press to select the UXGA 1 source 1
5 UXGA 2 Press to select the UXGA 1 source 2
6 HDMI 1 Press to select the HDMI source 1
7 HDMI 2 Press to select the HDMI source 2
8 IN
P
U
T
S
el
ec
to
r
B
ut
to
ns
2
USB Press to select the USB 3 source
9 PIP Button Toggles the picture-in-picture function (see section 7.2)
10 BLANK Button Press to toggle between a blank screen (blue or black screen) 4 and the
display
11 FREEZE Button Press to freeze/unfreeze the output video image 4
12 MENU Button Displays the OSD menu screen (toggle)
13 ENTER Button Moves to the next level in the OSD screen, or accepts a new parameter
14 Button Decreases the range by one step in the OSD screen or moves to the
previous level in the OSD screen
15
Button
Moves up one step (in the same level) in the OSD screen
16 Button Increases the range by one step in the OSD screen
17
Button
Moves down one step (in the same level) in the OSD screen
18 RESET TO XGA/720p Button Press and hold for a few seconds to reset to the default output
resolution (XGA/720p @60Hz) 5
19 PANEL LOCK Button Press to lock/unlock the front panel to prevent unintentional operation
20 USB Connector Connect to a USB drive to read JPEG files 6
1 And the appropriate audio source
2 When selected, button illuminates. See section 7.1 for details of how to program the INPUT SELECTOR buttons
3 JPEG files in EXIF format on a USB memory stick
4 Can be programmed to mute the audio signal at the same time (see Table 15)
5 Press and hold for about 2 seconds to reset to XGA; or press and hold for about 5 seconds to reset to 720p
6 Files must be in EXIF format
