CSC-7850 Communication Protocol
37
Control Type
Set Get
Function Parameter Description
0 1 26
0: Auto
1: HDMI
2: DVI
Output HDMI Type
0 1 27
0: Standard
1: Letterbox
2: Anamorphic
3: Virtual Wide
4: Native
5: Custom
Aspect Ratio
0 1 28 -64 ~ 64 H-Pan
0 1 29 -64 ~ 64 V-Pan
0 1 30 -32 ~ 32 H-Zoom
0 1 31 -32 ~ 32 V-Zoom
0 1 32
0: 100%
1: 150%
2: 200%
3: 225%
4: 250%
5: 275%
6: 300%
7: 325%
8: 350%
9: 375%
10: 400%
11: Custom
Zoom
0 1 33 100 ~ 400 Custom Zoom
0 1 34 0 ~ 31 Zoom H-Pan
0 1 35 0 ~ 31 Zoom V-Pan
0 1 36
0: On
1: Off
PIP On/Off
0 1 37
0: Picture-In-Picture
1: Picture + Picture
2: Split
PIP Type
0 1 38
0: Input 1
1: Input 2
2: Input 3
3: Input 4
4: VGA 1
5: VGA 2
6: HDMI 1
7: HDMI 2
8: USB
PIP Source
0 1 39
0: 1/25
1: 1/16
2: 1/9
3: 1/4
4: Custom
PIP Size
0 1 40 0 ~ 128 PIP H-Position
0 1 41 0 ~ 128 PIP V-Position
0 1 42 1 ~ 32 PIP H-Size
0 1 43
1 ~ 32
PIP V-Size
