BDx-Series Installation
5.2.2 Use of the Web Client
Type IP address or domain name of DVR server into the Internet Explorer’s Address bar and
click “GO”.
([e.g.] http://211.000.000.0 or http://dvrname.ipdvrfree.com)
If you are using non default port number for the web server, then type the address as below:
([e.g.] Port 8000: http://211.0.0.0:8000 or http://dvrname.ipdvrfree.com:8000)
If this log in window does not appear, check Network Setup of your DVR and ‘Port
forwarding settings’ of IP sharer (Router). Disable firewall block to the DVR
software, DVR Mediaserver and Apatch. Change web server port if your local ISP
blocks port 80.
When the monitoring window does not appear, disable ‘Popup Stopper’ in Tools of
Internet Explorer.
You can use the program by clicking LOG-IN Button after typing User ID, Password.
When you connect DVR for the first time, your client system download and install ActiveX. It
may take several minutes according to your network condition.
(Once Active X installed, the below Monitoring window appears directly from the next time.)
