9
Model 8 Channel Premium DVR 16 Channel Premium DVR
Video
In 8 BNC 16 BNC
Out 1VGA,& 1 BNC Main, 4 Spot Output
Audio
In 8 RCA (4 Mic in, 4 Line in) 16 RCA(4 Mic in,12 Line in)
Out 1 RCA (Line Out)
Device
Sensor In 8 TTL 16 TTL
Alarm Out 4 Relay + 4 TTL 4 Relay + 12 TTL
I/O Interface RS232, RS485, USB2.0 x 3, USB1.1 x 1 for Mouse
Display
Speed Real Time
Resolution 720 x 480 (NTSC), 720 x 576 (PAL)
Split Screen 1,4,9,PIP,Digital Zoom 1,4,9,13,16,PIP,Digital Zoom
Recording
Compression H.264 Codec
Speed /
Resolution
240fps@CIF(NTSC)
200fps@CIF(PAL)
120fps@Half D1(NTSC)
100fps@Half D1(PAL)
60fps@D1(NTSC)
50fps@D1(PAL)
480fps@CIF(NTSC)
400fps@CIF(PAL)
240fps@Half D1(NTSC)
200fps@Half D1(PAL)
120fps@D1(NTSC)
100fps@D1(PAL)
Picture Quality Very High, High, Standard, Low
Mode Time-lapse, Event, Time & Event, Emergency (Panic)
Playback
Display 1, 4, 9, Digital Zoom 1,4,9,13,16,Digital Zoom
Search Mode Calendar Search, Event Search, Text-In Search, Go to Time
Playback Mode
Multi Channel Normal & Reverse Play,
RW & FF ( x2, x4, x8, x16, x32), Frame to Frame, Pause
Network
Interface Ethernet (10/100 Base)
Protocol TCP/IP, HTTP, DHCP
Application Live, Playback, Setup, Notification (Callback, E-Mail)
Web Browse Internet Explorer 7 or higher
Storage 3xSATA HDD & 1xSATA ODD (or max. 4 SATA HDD w/o ODD)
Backup
CD & DVD-RW(Only HDE2424DV and HDS4848DV),
External HDD(USB), External USB Memory
Control
Front Panel Button, USB Mouse,
IR Remote Controller, Joystick Controller
OSD Graphic User Interface (Multilingual)
Approval FCC, CE, KCC
ROHS ROHS Compliance
Power Consumption DC12V, 6.67A (80W)
Operating Temperature 5°C ~ 40°C / 41°F~104°F
Operating Humidity 0%~80% / non-condensing
Dimension 430(W)x88(H)x428(D)mm / 16.93(W)x3.5(H)x16.85(D)inch
Weight 6Kg / 13lb (without HDD)
