37
In Email, Events can be notified to personal email addresses by text message.
•
E-Mail Interval: Select E-Mail Interval to set time interval between consequential events being
sent to remote site via email.
•
Recipient: Enter the email address of a recipient. Up to 5 recipients can be entered.
Note
: Any events occur between the pre-set interval time will not be sent to remote site. e.g. If the
interval is set as 30 seconds, only the events occur every 30 seconds since the first event will be sent
to remote site via email.
•
SMTP Server: Enter SMTP server using the virtual keyboard. SMTP server information can be
obtained from a system administrator.
•
Sender: Enter the address/name where the email is being sent from.
2-5-4. MENU > NETWORK > Transmission
In Transmission, Network transmission can be controlled with ips and bandwidth.
Note : Max. ips on Network transmission is 120ips@16ch-DVR, 60ips@8ch-DVR and 60ips@4ch-
DVR.(NTSC)
