5 . O v e r v i e w
Key Buttons
• Following buttons control zoom, focus, and auto focus functions.
W(WIDE) button : To widen the view. (ZOOM OUT)
T(TELE) button : To close in on a far object. (ZOOM IN)
N(NEAR) button : To see a near object clearly.
F(FAR) button : To see a far object clearly.
• Pressing the M(MENU) button prompts the main setup menu.
• Setup menu can be navigated using these buttons.
MENU(M) button : To access the main setup menu.
UP(T) button : To move the arrow indicator to up.
DOWN(W) button : To move the arrow indicator to down.
LEFT(N) button : To change date to down.
RIGHT(F) button : To change date to up.
Rear View
V i d e o O u t J a c k
P o w e r L E D
P o w e r I n p u t
T e r m i n a l
C o n t r o l
I n t e r f a c e
K e y B u t t o n s
8 9
