7 . O p e r a t i n g C a m e r a

SPECIAL Sub-Menu : MOTION DETECT

1. ZONE NAME

• Select the motion detection area number.
• Use the mask displayed on the screen to set positions.
• Can be selected WINDOW0~3 or BLOCK.

2. CONTROL

• Select enables or disables the motion detection feature.

3. H START

• Set the horizontal starting point for motion detection area.
• Select desired position from 11 to 178 in WINDOW0~3.
• Select desired position from 0 to 11 in BLOCK.

4. H END

• Set the horizontal terminating point for motion detection area.
• Select desired position from 11 to 178 in WINDOW0~3.
• Select desired position from 0 to 11 in BLOCK.

5. V START

• Set the vertical starting point for motion detection area.
• Select desired position from 6 to 128 in WINDOW0~3.
• Select desired position from 0 to 7 in BLOCK.

When there is a movement in the monitoring area, there will be an alarm, or
the user will be informed through communications or " MD " will display on the
screen.

MOTION DETECT

ZONE NAME

… WINDOW0

CONTROL

… ON

H START

… 16

H END

… 88

V START

… 9

V END

… 65

SENSITIVITY

… 8

ALARM … OSD&SERIAL

INITIAL

RETURN
