1) DZ mast + 25 mm
In accordance with VDI Guideline 2198 this specification sheet provides details of the standard truck only. Non-standard tyres, different masts, optional equipment, etc. may
result in different values.
Technical data in line with VDI 2198
Issue: 05/2012
Identifica
tion
1.1 Manufacturer (short form) Jungheinrich
1.2 Model DFG 316s DFG 320s TFG 316s TFG 320s
1.3 Drive Diesel Diesel LPG LPG
1.4 Manual, pedestrian, stand-on, seated, order picker operation seat
1.5 Load capacity/rated load Q t 1.6 2 1.6 2
1.6 Load centre distance c mm 500
1.8 Load distance x mm 398 1)
1.9 wheelbase y mm 1550
W
eights
2.1 Service weight kg 2800 3100 2800 3100
2.2 Axle load, w. load, front / rear kg 3870 / 520 4500 / 590 3860 / 530 4490 / 600
2.3 Axle load, w.o. load, front / rear kg 1340 / 1460 1350 / 1750 1330 / 1470 1340 / 1760
Wheels / chassis
3.1 Tyres SE (L)
3.2 Tyre size, at front mm 6.50-10 (14 PR)
3.3 Tyre size, at rear mm 18x7-8 (14 PR)
3.5 Wheels, number front/rear (× = driven wheels) 2x / 2
3.6 Track width, front b
10
mm 920
3.7 Track width, rear b
11
mm 870
Basic dimensions
4.1 Tilt of mast/fork carriage forward/backward α/ β ° 7/7
4.2 mast height (lowered) h
1
mm 2185
4.3 Free lift h
2
mm 150
4.4 Lift h
3
mm 3300
4.5 Extended mast height h
4
mm 3920
4.7 Height of overhead guard h
6
mm 2145
4.8 Seat height/stand height h
7
mm 1048
4.12 Coupling height h
10
mm 380
4.19 Overall length l
1
mm 3453 3473 3453 3473
4.20 Length incl. back of forks l
2
mm 2303 2323 2303 2323
4.21 Total width b
1
/b
2
mm 1100
4.22 fork dimensions s/e/l mm 40 / 100 / 1150
4.23 Fork carriage ISO 2328, class/type A, B 2A
4.24 fork carriage width b
3
mm 980
4.31 floor clearance with load under mast m1 mm 120
4.32 Floor clearance centre wheelbase m
2
mm 120
4.33 Aisle width for pallets 1000 × 1200 sideways Ast mm 3635 3653 3635 3653
4.34 Aisle width for pallets 800 × 1200 lengthways Ast mm 3835 3853 3835 3853
4.35 turning radius W
a
mm 2037 2055 2037 2055
4.36 Smallest pivot point distance b
13
mm 545
Performance da
ta
5.1 Travel speed, w. / w.o. load km/h 19.5 / 19.5
5.2 Lift speed, w. / w.o. load m/s 0.6 / 0.62
5.3 Lower speed, w. / w.o. load m/s 0.54 / 0.57
5.5 Drawbar pull w. / w.o. load N 12100 11900 12100 12400
5.7 Gradeability laden/unladen % 26 23 27 26
5.9.2 Acceleration laden/unladen to 15 m S 4.8 / 4.4 5.1 / 4.6 5 / 4.6 5.1 / 4.7
5.10 Service brake hydrostatic
5.11 parking brake Automatic activated multi disc brake
Combustion engine
7.1 Motor manufacturer / type VW / BXT VW / BXT VW / BEF VW / BEF
7.2 motor output according to ISO 1585 kW 29 29 31 31
7.3 rated revolutions per minute /min 2500
7.4 No. of cylinders 4
7.4.1 cubic capacity cm³ 1896 1896 1980 1980
7.5 fuel consumption acc. to VDI cycle l/h 2.3 2.6
7.5.1 fuel consumption acc. to VDI cycle kg/h 2.2 2.4
Misc.
8.1 type of drive control hydrostatic
8.2 working pressure for attachments bar 160
8.3 oil flow for attachments l/min 30
8.4 Sound pressure level at operator’s ear according to EN 12053 dB (A) 77 77 75 75
8.5 Trailer coupling, model/type DIN 15170/Typ H
