Technical data in line with VDI 2198
This specification sheet according to VDI regulation 2198 only provides technical values for the standard truck. Non-standard tyres, different masts, additional equipment, etc. could produce other values.
Right reserved for technical changes and improvements.
Identification
W
eights
Wheels,
Chassis
Basic Dimensions
Performance
Data
Electric
Engine
Others
1.1
Manufacturer (abbreviation)
Jungheinrich
Jungheinrich
Jungheinrich
1.1
1.2
Manufacturer’s type designation
EKX 513
EKX 515k
EKX 515
1.2
1.3
Drive Elektro
Elektro
Elektro
1.3
1.4
Operator type
Order picker/
Order picker/
Order picker/
1.4
Three-lateral stacker
Three-lateral stacker
Three-lateral stacker
1.5
Load capacity / rated load
Q (t)
1.25
1.5
1.5
1.5
1.6
Load centre distance
c (mm)
600
600
600
1.6
1.8
Load distance, centre of drive axle to fork
x (mm)
440
440
440
1.8
1.9
Wheelbase
y (mm)
1826
1926
2222
1.9
1.10 Centre drive wheel / counterweight
z (mm)
280
280
280
1.10
2.1
Service weight incl. battery (see line 6.5)
kg
6350
6750
7900
2.1
2.2
Axle loading, laden front / rear
kg
5720 / 1880
6190 / 2060
6590 / 2810
2.2
2.3
Axle loading, unladen front / rear
kg
3850 / 2500
3980 / 2770
4480 / 3420
2.3
3.1
Tyres
Vulkollan
®
Vulkollan
®
Vulkollan
®
3.1
3.2
Tyre size, front
380 x 192
380 x 192
380 x 192
3.2
3.3
Tyre size, rear
400 x 160
400 x 160
400 x 160
3.3
3.5
Wheels, number front rear (x = driven wheels)
2 / 1x
2 / 1x
2 / 1x
3.5
3.6
Tread, front
b
10
(mm)
1208
1308
1308
3.6
4.2
Closed mast height
h
1
(mm)
2955
2955
2955
4.2
4.4
Lift
h
3
(mm)
3500
3500
3500
4.4
4.5
Height, mast extended
h
4
(mm)
6050
6050
6050
4.5
4.7
Height of overhead guard (cabin)
h
6
(mm)
2550
2550
2550
4.7
4.8
Seat height / stand height
h
7
(mm)
430
430
430
4.8
4.11 Additional lift
h
9
(mm)
1780
1780
1780
4.11
4.14 Stand height, elevated
h
12
(mm)
3930
3930
3930
4.14
4.19 Overall length (without load)
l
1
(mm)
3250
3350
3646
4.19
4.20 Length to face of forks
l
2
(mm)
3164
3264
3560
4.20
4.21 Overall width
b
1
/ b
2
(mm)
1210 / 1400
1210 / 1500
1210 / 1500
4.21
4.22 Fork dimensions
s / e / l (mm)
50 x 120 x 1200
50 x 120 x 1200
50 x 120 x 1200
4.22
4.23 Fork carriage ISO 2328, class / type A, B
2 / B
2 / B
2 / B
4.23
4.24 Fork-carriage width
b
3
(mm)
480
480
480
4.24
4.25 Distance between fork-arms
b
5
(mm)
465
465
465
4.25
4.27 Width across guide rolls
b
6
(mm)
1500
1600
1600
4.27
4.29 Reach, lateral
b
7
(mm)
1300
1300
1300
4.29
4.30 Reach, lateral from vehicle centreline
b
8
(mm)
480
480
480
4.30
4.31 Ground clearance, laden, below mast
m
1
(mm)
80
80
80
4.31
4.32 Ground clearance, centre of wheelbase
m
2
(mm)
80
80
80
4.32
4.33 Aisle width for pallets 1200 x 800 mm
Ast (mm)
1640
1640
1640
4.33
4.35 Turning radius
Wa (mm)
2106
2206
2502
4.35
4.38 Distance to swivelling-fork pivot
l
8
(mm)
904
904
904
4.38
4.39 Total lift
h
3
+ h
9
(mm)
5280
5280
5280
4.39
4.40 Order picking height
h
12
+1600 (mm)
5530
5530
5530
4.40
4.41 Distance swivelling forks pivot point – steering rack
l
8
– x (mm)
464
464
464
4.41
4.42 Platform width
b
12
(mm)
800
800
800
4.42
4.43 Platform length
l
6
(mm)
1200
1200
1200
4.43
4.44 Clear width driver compartment entrance
(mm)
420
420
420
4.44
4.45 Clear driver compartment height inside
(mm)
2100
2100
2100
4.45
4.46 Driver compartment width outside
b
9
(mm)
1440
1440
1440
4.46
4.47 Width swivelling reach frame
b
14
(mm)
1440
1440
1440
4.47
4.48 Width extension arm
l
10
(mm)
172
172
172
4.48
4.49 Distance swivelling forks pivot point – fork carriage
r (mm)
154
154
154
4.49
5.1
Travel speed, laden / unladen (SF)
km/h
10.5 / 10.5
10.5 / 10.5
1
)
10.5 / 10.5
1
)
5.1
5.2
Lift speed, laden / unladen
m/s
0.42 / 0.42
0.47 / 0.47
2
)
0.47 / 0.47
2
)
5.2
5.3
Lowering speed, laden / unladen
m/s
0.45 / 0.45
0.45 / 0.45
0.45 / 0.45
5.3
5.4
Reaching speed, laden / unladen
m/s
0.25 / 0.25
3
)
0.25 / 0.25
3
)
0.25 / 0.25
3
)
5.4
5.10 Service brake
reverse current/regenerative reverse current/regenerative reverse current/regenerative
5.10
5.11 Parking brake
electric spring loaded/laminated electric spring loaded/laminated electric spring loaded/laminated
5.11
6.1
Drive motor rating S
2
60 min.
kW
7.6
7.6
7.6
6.1
6.2
Lift motor rating at S
3
25 %
kW
20
20
20
6.2
6.3
Battery acc. to DIN 43531 / 35 / 36 A, B, C, no
3 EPzS 465
4 EPzS 620
6 EPzS 930
6.3
6.4
Battery voltage, nominal capacity K
5
V/Ah
80 / 465
80 / 620
80 / 930
6.4
6.5
Battery weight
kg
1238
1558
2178
6.5
8.1
Type of drive control
AC drive control
AC drive control
AC drive control
8.1
8.4
Sound level at the driver’s ear according to EN 12 053
dB (A)
68
68
68
8.4
8.6
Steering
electric
electric
electric
8.6
1) possible in connection with performance package to 12 km/h
2) possible in connection with performance package to 0.52 m/s, combined lifting of main and additional lift to 0.7 m/s
3) possible in connection with performance package to 0.4 m/s
