EKX 513–515
s
h 9
h
3
m 1
h
7
h 6
h 12
h
1
h 4
z
m
2 y
l 6
l
c
r
b 7
b
8
b
14
b 5
b 12
e
x
l
8
l 1
l 2
b 1
b 6
b 2
Ast
Wa
Standard values for working aisle widths (mm)
with rail guidance
Pallet size Stacking-in depth Ast Ast
3
/ VDI Ast
3
/ VDI Ast
3
/ VDI Ast
3
*
theoretical theoretical theoretical theoretical practical
EKX 513 EKX 515k EKX 515
1200 x 800 1200 1640 3608 3708 4004 + 500
1200 x 1200 1200 1640 3967 4067 4363 + 500
800 x 1200 800 1440 3971 4071 4367 + 500
* The practical transfer aisle width is a reference value.
with inductive guidance
Pallet size Stacking-in depth Ast Ast
3
/ VDI Ast
3
/ VDI Ast
3
/ VDI Ast
3
*
theoretical theoretical theoretical theoretical practical
EKX 513 EKX 515k EKX 515
1200 x 800 1200 1720 3834 3934 4230 + 1000
1200 x 1200 1200 1720 4221 4321 4617 + 1000
800 x 1200 800 1490 4034 4134 4430 + 1000
* The practical transfer aisle width is a reference value.
