USING KEYPADLINC
Button Taps
Button Type Button’s LED Tap Double-tap
Toggle Off Turn Scene On Turn Scene Members On Instantly
Toggle On Turn Scene Off Turn Scene Members Off Instantly
Always On Either Turn Scene On Turn Scene Members On Instantly
Always Off Either Turn Scene Off Turn Scene Members Off Instantly
Press and Holds
Button Type Button’s LED
First Press and
Hold
Subsequent Press and Holds
Toggle Off
Brighten Scene until
release
Opposite of last Press and Hold
(e.g. if last was brightening, it will dim)
Toggle On
Dim Scene until
release
Opposite of last Press and Hold
(e.g. if last was brightening, it will dim)
Always On Either Brighten Scene until release
Always Off Either Dim Scene until release
Notes:
1) The Load will react just like the scene responders to button presses of MAIN when in 8-Button
configuration
2) The LED will mimic the on/off status of a dimmer whose scene level is 100% bright
INSTEON Scenes
Scene: One or more INSTEON devices which respond simultaneously to scene commands (e.g. button
presses). When the scene is activated (turned “on”), all devices return to the states they were at when the
scene was programmed. INSTEON scenes let you activate dramatic lighting moods at the touch of a
button. For example, you can set all the lights in a scene to dim to 50% or turn certain lights on while
turning others off. INSTEON scenes are easy to set up, just follow the directions below.
The below diagram provides an overview of the options available in the KeypadLinc Setup Mode and how
to navigate between the options. The Advanced Setup Features are highlighted in yellow.
