Chapter 1

9

Rear View

Base View

#

Icon

Item

Description

1

124-pin Acer ezDock
connector

Connects to Acer ezDock.

2

N/A

Battery

Powers the computer.

3

DC-in jack

Connects to an AC adapter.

#

Item

Description

1

Battery bay

Houses the computer’s battery pack.

2

Battery release latch

Releases the battery for removal.

3

Memory compartment

Houses the computer’s main memory.

4

Hard disk bay

Houses the computer’s hard disk (secured with screws).

5

Battery lock

Locks the battery in position.

Note:

#

Icon

Item

Description

#

Icon

Item

Description

Note:

#

Icon

Item

Description

#

Icon

Item

Description
