Hach-Lange NISE sc - Manual (Page 24)

24
Operation
SENSOR MENU
INFORMATION Information on the matrix correction used per parameter
NH4–N 1,2 Matrix correction used for ammonium
NO3–N 1,3 Matrix correction used for nitrate
K+ 1,2 Matrix correction used for potassium
CL 1,3 Matrix correction used for chloride
CONFIGURE
EDIT NAME
Enter or edit the name.
Up to 10 alphanumeric characters
MEAS UNITS Select either mg/L or ppm as the measurement unit
PARAMETERS Select NH
4
–N or NH
4
and/or NO
3
–N or NO
3
TEMP UNITS Selection of °C or °F as temperature unit
TEMP OFFSET Enter a temperature offset
RESPONSE TIME Entry of the response time (30 sec to 300 sec)
DATALOG INTRVL
Select the data log interval (OFF, 30 sec, 1 min, 2 min, 5 min,
10 min, 15 min and 30 min), 5 min is the factory setting
K+ COMPENSATE 1,2
Select automatic potassium compensation:
On
Off
0 = compensation OFF
0.1–2000 mg/L CL = Fixed compensation value
SET K+ CONC 1,2 Only shown when K+ COMPENSATE is OFF
CL COMPENSATE 1,3
Select automatic chloride compensation:
On
Off
0 = compensation OFF
0.1–2000 mg/L CL = Fixed compensation value
SET CL CONC 1,3 Only shown when CL COMPNSATE is OFF
FACTORY CONFIG Resets the configuration to the factory setting
DIAG/TEST
SENSOR INFO Information on the connected sensor
SENSOR NAME Name of the connected sensor
EDIT NAME Serial number or name of the measurement location
SERIAL NUMBER Serial number of the connected sensor
SENSOR TYPE Instrument designation of the connected sensor
CODE VERS Software version
CAL DATA
Data of the selected MATRIX correction and information about
slope and offset of the individual channels, for example
NH4–N 1,2 Matrix correction selected for ammonium
NO3–N 1,3 Matrix correction selected for nitrate
K+ 1,2 Matrix correction selected for potassium
CL 1,3 Matrix correction selected for chloride
