3.4 Setting the serial interface (V24)
The serial interface is used to transfer data to a computer or a Dr. Lange printer (e.g.
LD500). The necessary interface parameters are already specified for the Dr. Lange
products and can be selected. This option allows other interface parameters to be set in
accordance with the specifications for the connected peripheral device (PC or printer).
Sequence:
Select option
scroll with + or - and confirm
required protocol with
Protokol =free:
Select settings (bit/s,
databits, stopbits, parity,
handshake) in accordance with
the documentation of the
peripheral device, e.g. PC.
Protokol = LD2W:
for Dr. Lange printer, e.g. LD500,
too
Protokol = Lsoft
for Dr. Lange LUMISsoft
evaluation software
Protokol = no
Interface off
options
V24 PRN time
bit/s =
9600
+
-
ok
databits =
8
7
8
ok
stopbits =
1
1 1.5
2
ok
handshake = no
+
-
ok
parity = none
even odd no ok
protocol = free
+
-
ok
protocol =LD2W
+
-
ok
protocol = LSoft
+
-
ok
protocol =
no
+
-
ok
