English, 6 electrical connections – CAME BX-241 User Manual
Page 10

10
A
ll t
h
e d
at
a a
n
d i
n
fo
rm
at
io
n c
o
n
ta
in
ed h
er
ei
n
i
s c
o
n
si
d
er
ed
s
u
b
je
ct to c
h
an
g
e a
t a
n
y t
im
e a
n
d a
t o
u
r d
is
cr
et
io
n
ENGLISH
11
E
L1
L2
+10
-11
1
2
2
3P
M
N
2
C1
2
FC
F
FA
2
C3
F
FC
2
7
6.6 Electrical connections
FC F
M
FA
N
10
10 11
11 E1
E1
11
2
2
3
3
3P
3P C1
C1 C3
C3 7
7
24V AC +
-
L1
L2
M
230V (a.c.) power supply
24V(d.c.) motor
24V output in motion (e.g. fl ashing light 25W)
24V powering accessories max. 40W
Pushbutton stop (N.C.)
Pushbutton partial opening (N.O.)
Contact radio and/or pushbutton for controlled (see dip-switch 2-3)
Contact (N.C.) for «re-aperture during closure»
(24V-3W max.) gate-opened signal lamp
Contact (N.C.) for «partial stop»
Connection limit switch opens
Connection limit switch closes
Antenna connection
N.B. Maintain polarity when connecting photoelectric cells (DIR)
48
48 # .#
48
28
2
3
Pushbutton open (N.O.)
