CAME Myto ME - Manual (Page 9)

500
320
150
24h
Pa
g.
99
- M
an
u
al
c
od
e:
11
9
A
V
17
11
9
A
V
17
ve
r.
1
.0
1.
0
0
2
/2
0
10 © C
A
M
E c
an
ce
lli
auto
m
ati
ci
s.p.a. - T
h
e d
ata a
n
d i
nf
or
m
ati
on r
ep
orte
d i
n th
is
in
sta
lla
tio
n m
an
u
al
a
re s
u
sc
ep
tib
le to
c
h
an
g
e at a
ny ti
m
e a
n
d w
ith
ou
t o
b
lig
ati
on
o
n C
A
M
E c
an
ce
lli
auto
m
ati
ci
s.p.a. to n
otify u
se
rs.
ENGLISH
Setting up the fi xing /foundation casing
The following illustrations are also shown in the MYTO-C instruction sheet (for underground installation). Some exam-
ples are given, in that the space available for anchoring the operator and accessories varies depending on the overall dimen-
sions.
It is up to the installer, thus, to choose the most suitable solution.
Dig a pit for the box, set up junction boxes and corrugated tubes for connections coming from the junction box as well as a
drainage tube.
N.B.: the number of tubes depends on the type of system installed and any accessories.
Fill the hole with cement
Sink the box making sure the corrugated and drainage tube run through the holes you have set up.
Level the box with the ground and wait for it to dry for at least 24 hours.
Clean the inside of the box of any cement residue.
