CAME Myto ME - Manual (Page 8)

4
2
3
3
6
8
9
5
1
7
7
10
10
1
10
11
11
7
7
Pa
g.
88
- M
an
u
al
c
od
e:
11
9
A
V
17
11
9
A
V
17
ve
r.
1
.0
1.
0
0
2
/2
0
10 © C
A
M
E c
an
ce
lli
auto
m
ati
ci
s.p.a. - T
h
e d
ata a
n
d i
nf
or
m
ati
on r
ep
orte
d i
n th
is
in
sta
lla
tio
n m
an
u
al
a
re s
u
sc
ep
tib
le to
c
h
an
g
e at a
ny ti
m
e a
n
d w
ith
ou
t o
b
lig
ati
on
o
n C
A
M
E c
an
ce
lli
auto
m
ati
ci
s.p.a. to n
otify u
se
rs.
ENGLISH
1) MYTO automation
2) Control panel
3) Junction box for connecting to the gearmotor
4) Antenna
5) Flashing light
6) Keyswitch selector
7) Photocells
8) Junction pit
9) Drainage ditch
10) Mechanical stops
11) Photocells post
Standard installation
Type and section of cables
Tools and materials
Make sure you have all the tools and materials you will need for the installation at hand to work in total safety and compliance
with the current standards and regulations.
N.B.: If the cable length differs from that specified in the table, then you must determine the proper cable diameter in the basis of
the actual power draw by the connected devices and depending on the standards specified in CEI EN 60204-1.
For connections that require several, sequential loads, the sizes given on the table must be re-evaluated based on actual power
draw and distances.When connecting products that are not specified in this manual, please follow the documentation provided with
said products.
Connection Type of cable Length of cable 1 < 10 m L. of cable 10 < 20 m L. of cable 20 < 30 m
Control panel power supply 230
FROR CEI
20-22
CEI EN
50267-2-1
3G x 1,5 mm 2 3G x 2,5 mm 2 3G x 4 mm 2
Motor power supply 24V 3 x 1 mm 2 3 x 1,5 mm 2 3 x 2,5 mm 2
flashing lamp 2 x 0,5 mm 2 2 x 1 mm 2 2 x 1,5 mm 2
Photocell transmitters 2 x 0,5 mm 2 2 x 0.5 mm 2 2 x 0,5 mm 2
Photocell receivers 4 x 0,5 mm 2 4 x 0,5 mm 2 4 x 0,5 mm 2
Accessories power supply 2 x 0,5 mm 2 2 x 0,5 mm 2 2 x 1 mm 2
Control and safety devices 2 x 0,5 mm 2 2 x 0,5 mm 2 2 x 0,5 mm 2
Antenna connection RG58 max. 10 m
