13
Item Part # Item Description
1 151000 Top Cover
2 151002 Dust Cover
3 – Upper Front Cover
4 – Lower Front Door
5 151012 Base
6 – Drip Tray
7 – Drip Tray Grill
8 151030 Hot Water Tap w/Safety Device
9 151031 Cold Water Tap
10 Indicating Panel
11 151034 Main Water Tank Cover
12 151040 Left Side Panel (Looking @ Front)
13 151041 Right Side Panel (Looking @ Front)
14 151045 Front Mounting Bracket
15 151046 Insulation, For Water Line to
16 151047 Spring Latch, Front Door
17 – Screw, Metric, M4x8 Black
19 151050 Spring Clip
20 151051 Protective Rubber Grommet
21 151052 Shelf, Middle
22 151053 Compressor
23 151054 Shelf, Upper
24 151055 Mounting Plate, Water Taps
25 151056 Insulation, Cold Tank, Bottom
26 151057 Insulation, Cold Tank, Upper
27 151070 Cold Tank Assembly
28 – Water Connector, Inlet
29 – Seal, Cold Tank, Silicon,Upper
30 – Elbow, Silicon, T-Type
31 – Tube, 8mm, Silicon, 10 inches
32 – Tube, 160mm, Silicon, L-shaped
33 – Tube, 50mm, Silicon, L-Shaped
34 151075 Hot Water Tank
35 151076 Insulation, Hot Tank, Top
36 151077 Insulation, Hot Tank, Lower
37 – Tube, 175mm, Silicon L-Shaped
38 – Screw, Metric, M3x8
39 – Label of Lower Front Plate
40 151065 Hydraulic Type Floating Valve
Item Part # Item Description
41 – 1/4” RO Water Pipe
42 151081 Handle, Side Panel, L or R
44 151090 Back Panel
45 151095 Thermostat, Capillary, Cold
46 151098 Switch, Power
47 151100 Main Wiring
48 151060 Wire Condenser
49 151110 Nut, Plastic, White
50 151080 Filter Dryer
51 151111 Outlet Connector
52 151112 Outlet Connector Stem
53 151113 Nut, Tap, Cold Tank
54 151114 Tube, 75mm, Silicon, L-Shaped
55 – Screw, w/Washer, Metric, M4x7
58 151125 Power Cord Protector
59 151126 Power Cord
60 151130 Plug, Hot Water Drain
61 151131 Insulator, Rubber, Base
62 – Washer, Compressor Bolt
63 151135 Thermal Overload, Manual-Reset
64 151136 Thermostat, Hot Tank
65 151140 Fuseholder
66 151141 Fuse
67 151142 Fuse Wiring
68 – Cover, Hot Tank Vent Tube
69 – Air Filter, Vent Tube
70 – PCB, Front Display
71 – Screw, Metric, M4x12,Stainless
72 – Screw, Metric, M4x25, Black
73 – Screw, Metric, M4x6
74 – Screw, Flat Head, Compressor
75 – Screw, Metric, M3x4, Zinc
76 – Screw, Metric, M4x12, Zinc
77 151160 Insulated Sleeve
*78 151161 Ballast, 110V, NO ALARM
*79 89005 UV Lamp & Harness
*80 89007 Housing, Assy, UV
*81 89009 Pump, Assy
*82 89010 Ballast, Assy
*not shown
RePLAceMeNt PARt NUMBeRs
