STEP 7 CHARCOAL FILTER
Take the charcoal filter canister and fill 2/3 with coconut charcoal. Rinse a few times with
distilled water to remove any charcoal dust. (The sterilization drip tube must be removed prior
to operating the distiller, see step 8.) Place the nipple end into the small opening found on the
left-hand top of the water storage tank. Position distiller head onto the water storage tank
making sure that the two corner-legs, charcoal canister and the tank shut off control post line
up precisely.
Water Storage Tank
Distiller Head
Charcoal Canister
Corner Legs
Shut Off Control Post
O-Ring
04/08/04
9
