STEP 1
STORAGE TANK FAUCET
Remove the hex nut from the threaded faucet end. Push the gasket tightly over the threads up
against the faucet. Insert threaded faucet end with gasket through the opening found at the
bottom portion of the water storage tank. Take the hex nut in one hand and through the large
opening on top of the storage tank insert hand to find the faucet end. Place the hex nut on the
threaded faucet end. To tighten the nut, turn faucet counter-clockwise 1/8 of a turn. Hand
tighten the hex nut. Holding the nut, turn the faucet clockwise until it is upright. Do not push
the sight gauge, as it is fragile!
STEP 2 IMPURITIES DRAIN TUBE EXTENSION
Hex Nut
Gasket
Threaded Faucet End
Water Storage Tank
Faucet
Faucet Handle
Sight Gauge
Remove the compression nut and brass compression ring from the impurities drain valve. Slip
the compression nut over impurities drain tube so ½ of the nut is down onto the tube. Secure
the compression ring into the compression nut. Position the curved impurities drain tube away
from
the distiller. Turn the compression nut attached to the impurities drain tube onto the drain
valve and tighten securely with wrench or pliers.
Impurities Drain Valve
Compression Ring
Compression Nut
Imprurities Drain Tube
04/08/04
6
