Installation/Operation Supplement

F232148 (EN)

Dimensional Clearances

NOTE: The dimensions shown here are for
planning purposes only. They are approximate and
subject to normal manufacturing tolerances. If
exact dimensions are required for construction
purposes, contact the distributor or manufacturer.
We reserve the right to make changes at any time
without notice.

V-Computer

SF18VNV, SF25VNV, UF18VNV, and
UF25VNV Models

Both single and multiple machine installations require
specified minimum clearances on all sides of each
machine. Tables below show these clearances.

WE-6 Computer

SF35-85PV, UF35-85PV, SF135-250PV, and
UF135-250PV Models

Recommended Minimum Clearances

18 Pound

25 Pound

Minimum rear clearance, mm (in.)

305 (12)

Minimum clearance between machine and wall, mm (in.)

50 (2)

Minimum clearance between machines (side), mm (in.)

25 (1)

Minimum front clearance, mm (in.)

406 (16)

445 (17.5)

Table 4

Recommended Minimum Clearances

Pound

135

Pound

250 Pound

Standard

Forward

Tilt

Option*

Two-Way

Tilt

Option*

Minimum rear clearance,
mm (in.)

450 (18)

610 (24)

914 (36)

Minimum clearance between
machine and wall, mm (in.)

150 (6)

457 (18)

Minimum clearance between
machines (side), mm (in.)

25.4 (1)

457 (18)

Minimum front clearance,
mm (in.)

533 (21)

584 (23)

914 (36)

* Machines equipped with the tilt option require a minimum overhead clearance as well. Refer to

Figure 7

for the minimum

overhead clearance for the 250 pound capacity model with tilt option.

Table 5
