Installation/Operation Supplement
7 F232148 (EN) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Table 2 (Continued)
35 Pound 50 Pound 85 Pound
Cylinder Speeds
Gentle wash/reverse speed, RPM 26 26 26
Wash/reverse speed, RPM 43 40 41
Distribution/drain speed, RPM 77 73 65
Medium extract speed, RPM 325 305 280
High extract speed l, RPM 475 445 410
High extract speed 2, RPM 610 575 525
High extract speed 3, RPM 960 900 825
Centrifugal Force Data
Gentle wash/reverse centrifugal force, Gs 0.25 0.29 0.345
Wash/reverse centrifugal force, Gs 0.69 0.68 0.858
Distribution/drain centrifugal force, Gs 2.2 2.3 2.16
Medium extract centrifugal force, Gs 40 40 40
High extract 1 centrifugal force, Gs 85 84 85.8
High extract 2 centrifugal force, Gs 140 141 141
High extract 3 centrifugal force, Gs 345 345 348
Balance Detection
Vibration safety switch installed Standard Standard Standard
Direct Steam Heating (Optional)
Steam inlet connection size, mm (in.) DN15 DN15 (0.5) DN15 (0.5) DN15 (0.5)
Number of steam inlets 1 1 1
Steam required to raise bath temperature
10
° C, kg (10° F, lb.)
LOW 2.22 (1.6) 2.91 (2.42) 3.8 (5.2)
MED 2.52 (1.81) 2.42 (3.46) 4.3 (5.9)
HIGH 2.84 (2.04) 2.73 (3.80) 4.9 (6.9)
Average steam use per cycle, kg (bhp) 1.47 (23) 1.95 (30.6) 54.9 (3.5)
Electric Heating (Optional)
Total electric heating capacity, kW 15.6 23.4 31.2
Number of electrical heat elements 6 9 12
Electrical heat element size, kW 2.6 2.6 2.6
Time required to raise bath temperature
10°C, min. (10°F, min.) LOW 3.9 (2.6) 3.6 (2.4) 3.1 (4.8)
MED 4.5 (2.9) 4.2 (2.7) 3.5 (5.4)
HIGH 5.0 (3.3) 4.7 (3.1) 6.4 (4.1)
