Installation/Operation Supplement
F232148 (EN) 24 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Loading Using Tilt Option
Two-Way Tilt Machines
1. Open loading door and secure it to the door latch
on the right side of the machine.
2. Turn the selector on the pendant switch left to the
REVERSE position. Refer to Figure 18.
Figure 18
3. While holding down the ENABLE button, press
the REVERSE button to tilt backward.
4. Load the machine.
5. Turn the selector back to the CENTER position
to lower the machine.
6. Unlatch and close loading door.
Forward Tilt Machines
1. Open loading door and secure it to the door latch
on the right side of the machine.
2. Check that selector on the pendant switch is in
the CENTER position. If machine is in the
FORWARD position, turn the selector to the
CENTER position. While holding down the
ENABLE button, press the REVERSE button to
center the machine.
3. Load the machine.
4. Unlatch and close loading door.
Unloading Using Tilt Option
Forward and Two-Way Tilt Machines
1. Open loading door and secure it to the door latch
on the right side of the machine.
2. Turn the selector on the pendant switch right to
the FORWARD position. Refer to Figure 18.
3. While holding down the ENABLE button, press
the FORWARD button to tilt forward.
4. Unload the machine.
5. Turn the selector back to the CENTER position
to lower the machine.
6. Unlatch and close loading door.
U150R
1 Selector Dial
ENABLE
FORWARD
REVERSE
U150R3
1
