Installation/Operation Supplement
F232148 (EN)
20
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
250 Pound Capacity Models
with Forward and Two-Way Tilt Option
Figure 7
CFS219N
13°
2622 mm
(103 1/4")
914 mm (36") Recommended
762 mm (30") Allowable
330 mm
(13")
13°
475 mm (18")
Compacted fill dirt
15
2 mm (6") Mi
nim
u
m
F
loo
r Th
ic
k
n
e
s
s
330 mm
(13")
