Installation/Operation Supplement
F232148 (EN) 12 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
18 Pound 25 Pound
A 659 mm (26 in.) 686 mm (27 in.)
B 492 mm (19-13/32 in.) 508 mm (20 in.)
C 440 mm (17-5/16 in.) 432 mm (17 in.)
D 1161 mm (45-23/32 in.) 1232 mm (48-1/2 in.)
E 686 mm (27 in.) 762 mm (30 in.)
F 737 mm (29 in.) 813 mm (32 in.)
G 18 mm (23/32 in.) 18 mm (23/32 in.)
H 1143 mm (45 in.) 1214 mm (47-13/16 in.)
I 25 mm (1 in.) 25 mm (1 in.)
J 774 mm (30-1/2 in.) 876 mm (34-1/2 in.)
K 709 mm (27-15/16 in.) 816 mm (32-1/8 in.)
L 33 mm (1-5/16 in.) 38 mm (1-1/2 in.)
M 530 mm (20-29/32 in.) 597 mm (23-1/2 in.)
N 430 mm (16-29/32 in.) 495 mm (19-1/2 in.)
O 1074 mm (42-5/16 in.) 1074 mm (42-5/16 in.)
P 173 mm (6-13/16 in.) 211 mm (8-5/16 in.)
Q 86 mm (3-13/32 in.) 86 mm (3-13/32 in.)
R 1029 mm (40-1/2 in.) 1067 mm (42 in.)
S 114 mm (4-1/2 in.) 4-13/16 in. (122 mm)
