Installation/Operation Supplement
Installation
General Specifications
V-Computer
SF18VNV, SF25VNV, UF18VNV, and
UF25VNV Models
Refer to Table 1.
18 Pound 25 Pound
Overall Dimensions
Overall width, mm (in.) 737 (29.0) 813 (32.0)
Overall height, mm (in.) 1168 (46.0) 1232 (48.5)
Overall depth, mm (in.) 833 (32.8) 940 (37.0)
Weight and Shipping Information
Net weight, kg (lbs.) 250 (550) 318 (700)
Domestic shipping weight, kg (lbs.) 250 (550) 341 (750)
Domestic shipping volume, m
3
(ft
3
) 0.98 (34.6) N/A
Export shipping weight, kg (lbs.) 272 (600) 363 (800)
Export shipping volume, m
3
(ft
3
) 1.17 (41.44) N/A
Wash Cylinder Information
Cylinder diameter, mm (in.) 533 (21.0) 610 (24.0)
Cylinder depth, mm (in.) 349 (13.75) 406 (16.0)
Cylinder volume, l (ft
3
) 78 (2.76) 119 (4.19)
Perforation size, mm (in.) 4.77 (0.188) 4,77 (0.188)
Perforation open area, % 23 23
Load capacity (dry cloth weight), kg (lbs.) 8.16 (18) 11.34 (25)
Door Opening Information
Door opening size, mm (in.) 305 (12.0) 364 (14.345)
Height of door bottom above floor, mm (in.) 518 (20.4) 511 (20.1)
Water Consumption
Average water consumption
per cycle, l (gal.) HOT 87 (23) 106 (28)
COLD 42 (11) 49 (13)
Table 1 (Continued)
