Installation/Operation Supplement
13 F232148 (EN) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
WE-6 Computer
SF35PV and UF35PV Models
Figure 2
B145I
1 Cold Water 4 76 mm (3 in.) Reuse Drain Outlet
2 Hot Water 5 76 mm (3 in.) Drain Outlet
3 Steam Inlet
B145I
Front Side
Rear
1
2
3
4
5
814 mm
(32")
638 mm
(25 1/10")
559 mm
(22")
889 mm
(35")
992 mm
(39")
828 mm
(32 3/5")
813 mm
(32")
606 mm
(23 9/10")
1255 mm
(49 2/5")
1031 mm
(40 3/5")
300 mm
(11 4/5")
209 mm
(8 1/5")
279 mm
(11")
1323 mm
(52 1/10")
1408 mm
(55 2/5")
