Installation/Operation Supplement
F232148 (EN) 8 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
SF135PV, SF250PV, UF135PV, and
UF250PV Models
Refer to Table 3.
135 Pound 250 Pound
Standard Standard
Forward Tilt
Option
Two-Way
Tilt Option
Overall Dimensions
Overall width, mm (in.) 1803 (71) 1957 (77) 2006 (79) 2006 (79)
Overall height, mm (in.) 1829 (75) 2083 (82) 2235 (88) 2235 (88)
Overall depth, mm (in.) 1537 (60.5) 2235 (88) 2243 (88.3) 2311 91()
Weight and Shipping Information
Net weight, kg (lbs.) 1818 (4000) 3661 (8070) 4000 (8800) 4355 (9600)
Domestic shipping weight, kg (lbs.) 1909 (4200) 3951 (8270) 4000 (8800) 4445 (9800)
Domestic shipping volume, m
3
(ft
3
) 6.35 (227) 11.5 (409) 11.5 (409) 11.5 (409)
Export shipping weight, kg (lbs.) 2045 (4500) 3860 (8500) 4227 (9300) 4581 (10,100)
Export shipping volume, m
3
(ft
3
) 6.39 (248) 11.5 (409) 11.5 (409) 11.5 (409)
Wash Cylinder Information
Cylinder diameter, mm (in.) 1092 (43) 1321 (52) 1321 (52) 1321 (52)
Cylinder depth, mm (in.) 635 (25) 813 (32) 813 (32) 813 (32)
Cylinder volume, l (ft
3
) 596 (21.0) 1114 (39.3) 1114 (39.3) 1114 (39.3)
Perforation size, mm (in.) 4.77 (0.188) 4.76 (0.188) 4.76 (0.188) 4.76 (0.188)
Perforation open area, % 23 20 20 20
Door Opening Information
Door opening size, mm (in.) 584 (23) 724 (28.5) 724 (28.5) 724 (28.5)
Height of door bottom above floor, mm (in.) 718 (28.25) 784 (30.9) 937 (36.9) 937 (36.9)
Water Consumption
Average water consumption per cycle, l (gal.) HOT 590 (156) 905 (239) 905 (239) 905 (239)
COLD 437 (116) 424 (112) 424 (112) 424 (112)
Average hot water consumed per hour, l (gal.) 1023 (270) 1355 (358) 1355 (358) 1355 (358)
Power Consumption
Average power used per cycle, kWh 0.9 1.5 (Est.) 1.5 (Est.) 1.5 (Est.)
Average HVAC load, kcal/hr (Btu/hr) 375 (1500) 550 (2200) 550 (2200) 550 (2200)
Nominal sound emission, dBA 75 75 N/A N/A
Drive Train Information
Number of motors in drive train 1 1 1 1
Drive motor power, kW (HP) 7.5 (10) 18.5 (25) 18.5 (25) 18.5 (25)
Table 3 (Continued)
