Model 1358 – Brooks Instrument 1358 User Manual
Page 21
Installation and Operation Manual
X-VA-1358-eng
Part Number: 541B041AAG
September, 2012
5-3
Section 5 Parts List
Model 1358
Table 5-1 Model 1358 Parts List (Continued)
13
2
ADAPTER
3/8" NPT ADAPTER, NO LOCKNUT: 316 SS
014C023BMA
3/8" NPT ADAPTER, NO LOCKNUT: BRASS
014C023GGJ
3/8" NPT ADAPTER, FOR LOCKNUT: 316 SS
014C034BMA
3/8" NPT ADAPTER, FOR LOCKNUT: BRASS
014C034GGJ
1/2" NPT ADAPTER, NO LOCKNUT: 316 SS
014C028BME
1/2" NPT ADAPTER, NO LOCKNUT: BRASS
014C028GGJ
14
2
ADAPTER O-RING
VITON
375B908QTA
BUNA-N
375B908SUA
EPM
375B908SYA
KALREZ
375B908TTA
15
2
LOCKNUT FOR FRONT OF PANEL MOUNTING
573B018AC0
16
1
LEFT SIDE PLATE
SS SIDE PLATE
614A008BMF
ALUMINUM SIDE PLATE
614A008FBJ
SS SIDE PLATE FOR LEFT DET. SCALE
614A175BMF
ALUMINUM SIDE PLATE FOR LEFT DET. SCALE
614A175FBJ
17
1
RIGHT SIDE PLATE
SS SIDE PLATE
614A008BMF
ALUMINUM SIDE PLATE
614A008FBJ
SS SIDE PLATE FOR RIGHT DET. SCALE
614A174BMF
ALUMINUM SIDE PLATE FOR RIGHT DET. SCALE
614A174FBJ
18
1
RIGHT DETACHABLE SCALE
PER S/N
19
2
SCALE SCREW
753L267CEA
20
2
SCALE WASHER
962A006AWA
21
2
SCALE NUT
573D012AWA
22
1
FRONT WINDOW
794A012NZ%
23
1
BACK WINDOW
615A012PBA
24
16
SCREWS-SIDE PLATES & WINDOWS
753L424AWA
25
1
PLASTIC BEZEL
BEZEL, W/VALVE
075B013NZD
BEZEL, NO VALVE
075B025NZD
26
4
BEZEL MOUNTING SCREW
753A429AWA
27
1
VALVE KNOB
498C080NCQ
28
1
VALVE KNOB COVER
219Z237NCQ
29
1
VALVE PACKING NUT
573R012GGJ
30
2
VALVE O-RING
VITON
375B011QTA
BUNA-N
375B011SUA
EPM
375B011SYA
KALREZ
375B011TTA
