Installation and Operation Manual
X-VA-1358-eng
Part Number: 541B041AAG
September, 2012
5-2
Section 5 Parts List
Model 1358
Table 5-1 Model 1358 Parts List
REF NO QTY DESCRIPTION PART NO
1 1 GLASS METERING TUBE PER S/N
2 1 316 S.S. FLOAT
8-RV-8
S346B148BMA
8-RJ-10 349D078BMA
8-RJ-23 349D080BMA
8-RJ-30 349D077BMA
8-RJ-39 349D076BMA
3 1 INLET FLOAT STOP
SPRING FLOAT STOP 0.8, 3.5 & 5 GPM
820B253BMA
SPRING FLOAT STOP 1.5 & 2.5 GPM 820B254BMA
4 1 OUTLET FLOAT STOP
SPRING FLOAT STOP 0.8, 3.5 & 5 GPM
820B253BMA
SPRING FLOAT STOP 1.5 & 2.5 GPM 820B254BMA
5 2 TUBE SEAL PACKING
VITON
589B043QTA
EPM 589B043SYA
NEOPRENE 589B043TDA
TEFLON 589B241QMA
6 1 SEAL END FITTING
316 SS
325G001BMF
BRASS 325G001GGL
7 1 SEAL SPINDLE
316 SS
817A055BMA
BRASS 817A055GGJ
8 1 SEAL SPINDLE O-RING
VITON
375B010QTA
BUNA-N 375B010SUA
EPM 375B010SYA
KALREZ 375B010TTA
9 1 SEAL PLUG O-RING
VITON
375B211QTA
BUNA-N 375B211SUA
EPM 375B211SYA
KALREZ 375B211TTA
10 1 JACKSCREW PLUG
316 SS
618J005BMA
BRASS 618J005GGJ
11 1 JACKSCREW PLUG O-RING
VITON
375B905QTA
BUNA-N 375B905SUA
EPM 375B905SYA
KALREZ 375B905TTA
12 1 VALVE END FITTING
W/VALVE: 316 SS
325H002BMF
W/VALVE: BRASS 325H002GGL
W/VALVE, FOR BASEPLATE: 316 SS 325H064BMF
W/VALVE, FOR BASEPLATE: BRASS 325H064GGL
NO VALVE: 316 SS 325J006BMF
NO VALVE: BRASS 325J006GGL
