Section 1 Introduction
Model 1358
Tube Packing
Standard: Neoprene
® (Brass meters), Viton-A ® fluoroelastomers
(316 stainless steel meters).
Optional: Teflon
® , EPM
O-rings
Standard: Buna-N (Brass meters), Viton-A
Optional: (316 stainless steel meters): EPM, Kalrez
®
Figure 1-1 Model 1358 Dimensions
1-4 Optional Equipment
Mounting
Flush panel mounting bezel
Front of panel mounting locknuts
Standard Needle Valve
The standard needle valve can be supplied integrally mounted or externally
piped to the inlet or outlet of the instrument.
Flow Contollers
Flow controllers can be supplied integrally mounted or externally piped to
the inlet or outlet of the instrument. For the flow controller's complete
instruction manual go to our website: BrooksInstrument.com, select
Documentation, Precision Valves & Flow Controllers, select FC8800, or
FC8900.
Inch
MM
