Brooks Instrument IPT122 2 Indicating Pressure Transmitters" - Manual (Page 11)

Installation and Operation Manual
X-PR-IPT122-eng
Part Number 541B151AAG
April, 2010
IPT122 Series
2-1
Section 2 Installation
2-1 General
This section provides installation instructions for the Brooks ® IPT122
Series Indicating Pressure Switch devices . Refer to Section 1 of this
manual for the dimensions and process connections.
Prepare the pressure transmitter for use.
Verify integrity of the seal by appropriate helium leak-testing procedures.
Turn the gas flow ON then OFF, 10 times to remove any particles
generated during installation. (The flow rate used should at least equal the
process flow specifications.)
Mechanical Installation is complete. Complete electrical connections as
noted in the next section.
2-2 Receipt of Equipment
When the instrument is received, the outside packing case should be
checked for damage incurred during shipment. If the packing case is
damaged, the local carrier should be notified at once regarding his liability.
A report should be submitted to your nearest Product Service Department.
Brooks Instrument
407 W. Vine Street
P.O. Box 903
Hatfield, PA 19440 USA
Toll Free (888) 554 FLOW (3569)
Tel (215) 362 3700
Fax (215) 362 3745
E-mail: [email protected]
www.BrooksInstrument.com
Brooks Instrument Brooks Instrument
Neonstraat 3 1-4-4 Kitasuna Koto-Ku
6718 WX Ede, Netherlands Tokyo, 136-0073 Japan
P.O. Box 428 Tel +81 (0) 3 5633 7100
6710 BK Ede, Netherlands Fax +81 (0) 3 5633 7101
Tel +31 (0) 318 549 300 Email: [email protected]
Fax +31 (0) 318 549 309
E-mail: [email protected]
Remove the envelope containing the packing list. Carefully remove the
instrument from the packing case. Make sure spare parts are not
discarded with the packing materials. Inspect for damaged or missing
parts.
2-3 Recommended Storage Practice
If intermediate or long-term storage of equipment is required, it is
recommended that the equipment be stored in accordance with the
following:
a. Within the original shipping container.
b. Ambient temperature 21°C (70°F) nominal, 79°C (175°F) maximum
-29°C (-20°F) minimum.
c. Relative humidity 45% nominal, 60% maximum, 25% minimum.
