Step 3:
After system restarts, press F10 to enter the NVIDIA RAID setup utility. Select Striping in the RAID Mode
filed (Figure 21). Move to the Free Disks section with the TAB key. Select the desired disk and use the
RIGHT ARROW key to add it to Array Disks menu.
Figure 21
Step 4:
After all the settings, press F7 to complete the configuration. When prompted to Clear Disk Data (Figure
22), press N. Then press CTRL+X to exit the NVIDIA RAID BIOS. Restart the computer to boot into
Windows 2000.
Figure 22
MediaShield Utility Mar 22 2006
- Define a New Array -
RAID Mode: Striping Striping Block: Optimal
[ ] Add
[ ] Del
[ESC] Quit [F6] Back [F7] Finish [TAB] Navigate [ ] Select [ENTER] Popup
2.0.M ST3120026AS 111.78G
2.1.M ST3120026AS 111.78G
Free Disks
Loc
Disk Model Capacity
Array Disks
Loc
Disk Model Capacity
RAID Mode: Striping Striping Block: Optimal
[ ] Add
[ ] Del
[ESC] Quit [F6] Back [F7] Finish [TAB] Navigate [ ] Select [ENTER] Popup
1.0.M ST3120026AS 111.79G
1.1.M ST3120026AS 111.79G
MediaShield Utility Mar 22 2006
- Define a New Array -
Array Disks
Loc Disk Model Capacity
Free Disks
Loc
Disk Model Capacity
Clear disk data ?
[Y] YES [N] NO
