GA-M55S-S3 Motherboard - 36 -
English
2-3 Integrated Peripherals
CMOS Setup Utility-Copyright (C) 1984-2006 Award Software
Integrated Peripherals
Serial-ATA RAID Config [Press Enter]
On-Chip IDE Channel0 [Enabled]
On-Chip MAC Lan [Auto]
NV Serial-ATA Controller [All Enabled]
IDE Prefetch Moed [Enabled]
Onboard Audio Function [Auto]
SMART LAN [Press Enter]
Onboard 1394 [Enabled]
Onboard LAN Boot ROM [Disabled]
Onboard Serial Port 1 [3F8/IRQ4]
Onboard Parallel Port [378/IRQ7]
Parallel Port Mode [SPP]
x ECP Mode Use DMA 3
On-Chip USB [V1.1+V2.0]
USB Keyboard Support [Disabled]
USB Mouse Support [Disabled]
Legacy USB storage detect [Enabled]
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
NV SATA RAID function
Enabled Allows users to configure individual SATA channels as RAID or ATA mode.
Disabled Disable the RAID function for all of the onboard SATA channels. (Default value)
NV SATA 1 Primary RAID
Enabled Enable RAID function for the first channel of the first SATA controller. (Default value)
Disabled Disable the RAID function of this channel. It will operate in ATA mode.
NV SATA 1 Secondary RAID
Enabled Enable RAID function for the second channel of the first SATA controller. (Default value)
Disabled Disable the RAID function of this channel. It will operate in ATA mode.
NV SATA 2 Primary RAID
Enabled Enable RAID function for the first channel of the second SATA controller. (Default value)
Disabled Disable the RAID function of this channel. It will operate in ATA mode.
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Integrated Peripherals
Serial-ATA RAID Config
CMOS Setup Utility-Copyright (C) 1984-2006 Award Software
Serial-ATA RAID Config
Item Help
Menu Level NV SATA RAID function [Disabled]
x NV SATA 1 Primary RAID Enabled
x NV SATA 1 Secondary RAID Enabled
x NV SATA 2 Primary RAID Enabled
x NV SATA 2 Secondary RAID Enabled
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F11/12: Profile F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
