Testing the Modem

ThinFax 336E

This section provides information on how to verify the modem functionality using

the built-in Terminal program in Windows CE H/PC.

NOTE:
What type of telephone line is yours? Analog or Digital?

Check your telephone line, as the ThinFax 336 can be connected to an ANALOG Line
ONLY!
(Normal house-hold line)

Terminal program

To start the Terminal you need to tap on My Handheld PC, then Program Files, and then
Communication. The H/PC should show the following screens.

Figure 7 Program Files

Tap on the Terminal icon.

Figure 8 Communication Folder

On the Terminal screen, tap on Make a New Connection. Figure 9

Figure 9 Terminal

In the Session Properties, in the Select a Modem pull-down menu should show the
ThinFax 336E modem. Figure 10

Figure 10 Select a Modem (ThinFax 336)
