Arrow on camera base
Arrow on camera
5.Re-attach the
dome cover.
Align the arrows
as shown in the
diagram to
ensure a
waterproof seal.
Use the allen key
to tighten the
tamper screws.
module (inside camera) NOTE:Makesure
dome cover cord
does not catch in
rubber seal
Correct Arrow Alignment
Arrow on dome cover
10. DIMENSIONS
Camera
Dimensions
Base Hole Screw
Dimensions
