Configuration
8.4 Web Interface/Live Video Overview
Camera
configuration
menus
Click and drag to zoom in. Right-click and
select ZoomOut to zoom out.
Double-click inside window for full-screen
Select Stream
TIP: Select stream2 for better performance for remote
connections. Stream2 has a lower resolution than stream1.
The Live video page appears when you log into the camera. Live video
requires an ActiveX® plug-in or Adobe Flash Player.
8.4.1 Live Video Menu
You can right-click on the live video area to bring up the Live Video Menu.
Right-click on the video area to
open the Live Video Menu
The Live Video Menu contains the following options:
• Full Screen: Open the video in full screen. Press ESC to exit full screen.
• Sensor Config: Configure the camera sensor settings. See “8.17 Sensor
Configuration” on page 55.
• ZoomIn: Zoom in one level.
• ZoomOut: Zoom out one level.
• Restore Panorama: Zoom out all the way.
8.4.2 Configuring Camera Settings
• Click the options on the left to configure camera settings. Setting options
are detailed in the remainder of this section.
Click to select
camera menus
TIP: Some sub-menus have a Reset button. This button will reset the
sub-menu options to factory defaults. You then have to click OK to save
changes.
