CAMERA ELI‐EDC USER MANUAL eLineTechnology.com
Page | 8
On‐Screen Display (OSD) Settings
On the OSD control device on the cable, hit the center button to activate the OSD settings. The menu as
below will appear. Use the button by moving up/down/left/right and depressing as ‘Enter’ to change
OSD settings. For further definition of each setting see the eLine web site under Support.
http://www.elinetechnology.com.
Lens ELC DC
Exposure HBLC D‐WDR BLC HLI/D‐WDR
AGC OFF LOW MIDDLE HIGH
3D DNR OFF LOW MIDDLE HIGH
SENSE‐UP AUTO OFF X2 X4 X8 X16 X32 X64 X128
X256 X512
EXIT
COLOR WB MODE ATW MANUAL AWC>PUSH AWC
R‐Y‐GAIN O‐256
B‐Y‐GAIN 0‐256
EXIT
DAY & NIGHT D&N MODE AUTO COLOR B&W EXT
FUNCTION MIRROR ON OFF
SHARPNESS 0‐30
LSC ON(0‐30) OFF
MOTION MOTION ON OFF
AREA SEL. TOP BOTTOM LEFT RIGHT
SENSITI 0‐30
DISPLAY OFF ICON TRACE
HOLD TIME 0‐15 Unit: sec
ALARM ON OFF
EXIT
PRIVACY MASK1‐MASK8 ON OFF
SETUP TITLE OFF ON: 64 characters
DPC OFF MANUAL: WHITE THR 0‐255 BLACK
THR 0‐255
DPC LEVEL 0‐255
OLPF 650 850
MONITOR CRT LCD
GAMA 0.45 0.60 1.0 USER
EXIT
SYSTEM CAMERA ID 0‐255
COMMUNI PROTOCOL: PELCO‐D
BAUDRATE: 2400 4800 9600 bps
RETURN
LANGUAGE CHINESE ENGLISH
EXIT
EXIT FACTORY SET
SAVE & EXIT
EXIT
