QUICK BOOT
It is highly recommended to configure the DXN to use the Quick Boot process as described in the following
To enable Quick Boot from the main screen select Update (System ► Update) and then press the Set Up Quick Boot button
Site Name 0.00 GPM
10/12/2011
13:24
System Site I/O Cal Adv Display Meter Log
Update Comm Time PC Storage Disk Power ENet Misc
Set Up Quick Boot
Quit Meter to Manage / Update
GUI -> Rev A =
V
001.1 20111116.0
DSP -> Rev A =
V
001.1 20111116.0
DASH -> Rev A =
V
001.0 20111112.0
BIOS -> Rev A =
V
001.0 20111112.0
OS -> Rev A = V 001.0 20111112.0
The application reverts to the Normal Start APP screen Press the Start Flow Meter button The DXN enters a short hibernation
process and then shuts down
Series DXN
Normal Start APP
dynasonics.com 800-535-3569 ©2012 Racine Federated Inc., all rights reserved
Start Flowmeter
Flowmeter Administration Tools
Insert USB Update Drive
On the next power up, the unit starts in Quick Boot mode
