4
PRINTPAD SERIES OF PRINTERS USER'S GUIDE
Using a Handheld Computer (HHC)
Using a HHC with Standard PrintPAD Series
Printers
1. Insert the handheld into the cavity and press down
until the handheld is firmly seated (Figure 3).
Using a HHC with PrintPAD-9000 Printers
1. Insert the handheld into the cavity by slightly
rotating it into the side channels.
2. Press down until the handheld is fully seated
(Figure 4).
3. Raise the yellow locking lever. When locked, the
lever clicks into place (Figure 5).
Figure 3
Locking
lever
Figure 4 Figure 5
