7
PRINTPAD SERIES OF PRINTERS USER'S GUIDE
4. Feed the end of the paper under the roller until the
paper exits from the top of the printhead (Figure 9).
Verify the paper exits straight.
5. Lower the printhead release lever (Figure 10).
6. Feed the end of paper through opening in the
printer's cover.
7. Remove any excess paper by grasping the top
corner of the paper and pulling it up and away.
8. Close and latch the printer's cover.
Printing a Self-Test
1. Open the printer's cover.
2. Press the red self-test button until the printer starts
to print (Figure 11).
3. After printing starts, release the red self-test button.
Roller
Figure 9 Figure 10
Figure 11
Self-test button
