Page 4: Open view closed view
1
PRINTPAD MC70 USER'S GUIDE
PrintPad MC70 Printer Views
Open View
Closed View
Roller
Battery/
battery
cavity
Battery clip
Paper/paper
cavity
Data port
Self-test
button
Charge LED
Battery
Status LED
Radio LED
Power LED
Battery
Status
Radio LED
Power LED
Handheld cavity
Latch
Paper opening
Hand strap
LEDs
DC power port
DEX/UCS port
CardReader slot
