8
PRINTPAD MC70 USER'S GUIDE
Loading Paper
1. Press a new roll of paper into the paper cavity. The
end of the roll should exit from the bottom of the
paper cavity and face the printer's roller (Figure 6).
When properly installed, the roll of paper “latches”
into place.
2. Raise the printhead release lever until it is fully
open. The lever clicks midway at the partially open
position; however, do not stop here, continue to
raise the lever until it is fully open (Figure 7).
3. Wake up the printer by momentarily pressing the
red self-test button (Figure 8).
4. Feed the end of the paper under the roller until the
paper exits from the top of the printhead (Figure 9).
The printer has an auto advance feature that will aid
Figure 6
Roller
End of paper roll
Paper latch
Figure 7
Figure 8
Printhead
release
lever
Self-
test
button
