16
Label Formatting Mode
As mentioned earlier, Label Formatting mode utilizes the current printer configuration to process
each tag printed. (For exception processing and fault handling, see the
KcFH command.) The
specification for RFID programming is contained in the data fields of the DPL label format, as
described below.
Wx / W1x: RFID
Syntax for RFID (spaces shown for readability):
a bbb c d eee ffff gggg jj…j
Where:
Field Valid Inputs Meaning
a 1, 2, and 3
Operation to perform, where:
1 = Read (report to host)
2 = Write
3 = Write / Verify
bbb Wnx RFID Hexadecimal Operation, where no ‘n’ is an implied 1.
c 0 Not Used
d 0 Not Used
eee xyy
Lock after write, where:
x = 0 – Use printer setup to determine if lock is performed.
x = 1 – Lock after write.
yy = Lock Code, representing a 2-character hex value (UHF
Alien only).
ffff 0000 – 9998 Starting block number to begin writing (HF only).
gggg 0000 Not Used
jj…j
Valid
hexadecimal
pairs per
character
followed by a
termination
character.
Data to write to the tag.
 Note: UHF must be 16 or 24.
The following example encodes, starting at block 001, “Datamax writes RFID best”:
L
D11
2W1x0000000010000446174616D61782077726974657320524649442062657374
E
