Datamax-O'Neil I-Class RFID HF & UHF Option User Manual
Page 13
11
STX KtD
Write Data Storage Format Identifier (DSFID) to Tag
This command writes the DSFID data to the tag.
Syntax:
Where:
a
- The number of retry attempts, 0-9.
b
- Lock the Data Storage Format Identifier (DSFID) after writing:
0 = No Protection
1 = Write Protect
cc
- Two character DFSID value representing one byte.
Sample:
The sample writes 0xC3 DSFID byte, locking value, retrying nine times, if necessary.
STX KtE
Write Electronic Article Surveillance (EAS) Bit
This command writes the EAS bit for Philips ISO tags.
Syntax:
Where:
a
- The number of retry attempts, 0-9.
b
- Electronic Article Surveillance (EAS) option:
0 = Set EAS
1 = Reset EAS
2 = Test EAS
cc
- Two character Manufacturer’s Code, representing one byte.
Sample:
The sample writes the EAS bit for Philips (0x04), retrying nine times, if necessary.
STX KtH
Read and Feedback Tag Information to Host
This command returns the tag info to host.
Note: This command only works when the Data Flag for the tag is 0x0F (i.e., when the tag contains
DSFID, AFI, VICC and IC data.
Syntax:
Sample Feedback:
DATA FLAG: 0x0F
TAG ID: E004010000751412
DSFID: 0xE3
AFI: 0x01
NUM BLK: 0x1B
BLK SIZ: 0x03
IC REF: 0x01
