Datamax-O'Neil H-Class Present Sensor Option User Manual
Page 3
1
Overview
This document describes the contents, installation, and use of the Present Sensor option for the H-Class
printer. After verifying the contents of the kit, follow the steps below to install and begin using the option.
A maintenance procedure is also included, so keep this documentation for future reference.
CAUTION
For your safety and to avoid equipment damage, always turn ‘Off’ power and unplug the
printer’s power cord before beginning this installation and when performing service.
Contents of the Present Sensor Option
This kit contains the following item:
Present Sensor Assembly
Step 1: Preparing the Printer
A) Turn ‘Off’ the Power Switch and unplug the
power cord from the AC Receptacle.
AC Receptacle
Power Switch
B) Press down on the Catch, then pull forward to
remove the Door.
Door
Catch
