Analog Way Broad Scan HD User Manual
Page 42
APPENDIX A / ANNEXE A
BROAD SCAN (HD/SDI)
COMMAND RESPONSE
COMMAND DESCRIPTION
TYPE
VALUE /VALEUR
COMMANDE RÉPONSE
DESCRIPTION DE LA COMMANDE
MIN MAX
DESCRIPTION
COMMUNICATION COMMANDS / COMMANDES DE COMMUNICATION
ne
ne
Communication port selection
Rd/Wr
0
1
0 = RS232
1 = LAN
nr
nr
Reset of the LAN parameters.
Rd/Wr
0
1
1 = reset.
ns
ns
Store the LAN parameters.
Rd/Wr
0
1
1 = store.
na
na
IP address and port selection (for
modification)
Rd/Wr
0
3
0 = all IP address / ports
1 = IP local address / local port
2 = IP remote address / remote port
3 = IP gateway address.
nw
nw
First byte of the address selected by the
na command.
Rd/Wr
0
255
nx
nx
Second byte of the address selected by
the na command.
Rd/Wr
0
255
ny
ny
Third byte of the address selected by
the na command.
Rd/Wr
0
255
nz
nz
Forth byte of the address selected by the
na command.
Rd/Wr
0
255
np
np
Number of the port (local or remote)
selected by the na command.
Rd/Wr
0
65500
local port: 10000 to 10999.
remote port: 0 to 65500.
nk
nk
netmask.
Rd/Wr
0
24
Value = number of bit to 0 (from right).
example: 2 255.255.255.252
3 255.255.255.248
.............
8 255.255.255.0.............
24 255.0.0.0
nt
TCP
protocol selection.
Rd/Wr
0
1
0 = UDP
1 = TCP
CONTROLS COMMANDS / COMMANDES DE CONTRÔLE
xU
xU
Device version
Rd
0
65535 The value is displayed in decimal and should be
converting in hexadecimal to obtain the version.
Example: xU262262 (dec) = 106 (hex)
106 = Version 1.06
ZT
ZT
Zoom type
Rd/Wr
0
1
0 = Direct zoom
1 = Dynamic zoom
YL
YL
Auto frame
Rd/Wr
0
1
0 = OFF
1 = ON
YK
YK
Front panel locking selection.
Rd/Wr
0
3
0 = unlocks all buttons.
1 = locks Menu buttons.
3 = locks all buttons
wS
wS
Standby function
Rd/Wr
0
2
1 = Active Standby
1 = Wake up the device
ws
ws
Standby status
Rd/Wr
0
2
wt
wt
Stand by time
Rd/Wr
0
8
0 = 0 second
1 = 1 min
2 = 5 min
3 = 10 min
4 = 15 min
5 = 30 min
6 = 60 min
7 = 90 min
8 = 120 min
wm
wm
Standby mode activation
Rd/Wr
0
2
0 = Sync.loss
1 = Standby time
2 = Sync. loss + time
YE
YE
Erase memories
Rd/Wr
0
1
1 = set all the parameters to the default value
(automatic reset).
YR
YR
Default value.
Rd/Wr
0
1
1 = erase all memories (automatic reset).
NOTE:
Rd = Read only command / Commande de lecture.
Rd/Wr = Read and write command / Commande de lecture et d'écriture.
PAGE 42
