BROAD SCAN (HD/SDI)
Chapter 7 : TECHNICAL SPECIFICATIONS
7-1. COMPUTER INPUTS
• ANALOG COMPUTER INPUT
Connector: HD15 female.
Line frequency: From 31.5 kHz to 130 kHz.
Frame frequency: Up to 130 Hz.
Resolution: Up to 1600 x 1200
Signal & Sync. type: RGBHV, RGB/S, RGsB (Sync On Green).
Level: R, G, B: 0.7 Vp/p.
H & V Sync: TTL.
Composite Sync: TTL and 0.3 V.
SOG (Sync On Green): 0.3 V.
Impedance: R, G, B: 75 Ohm
H: Hi-Z or 75 Ohm.
V: Hi-Z
• DIGITAL COMPUTER INPUT
Connector: DVI-I female.
Format: Digital Visual Interface (DVI-D)
Resolution: Up to 1600 x 1200 @ 60Hz.
Up to 1920 x 1200 @ 60Hz RB (Reduced Blanking).
• AUDIO INPUT*
Connectors: 2xRCA female.
Type: Stereo unbalanced.
Levels: Vi = + 18 dBU max.
Zi = 44
kΩ unbalanced.
Gain: 0 dB to -
∞ dB.
7-2. VIDEO OUTPUTS
• RGB/S VIDEO
Connectors: 4 BNC female.
Frequency: 15.625 kHz / 50 Hz (625 lines).
15.734 kHz / 59.94 Hz (525 lines).
Level: R, G, B : 0.7 Vp/p.
Sync: 5 V TTL.
SOG: 0.3 Vp/p.
Impedance: 75 Ohm.
• COMPONENT (YUV)
Connectors: 3 BNC female.
Frequency: 15.625 kHz / 50 Hz (625 lines).
15.734 kHz / 59.94 Hz (525 lines).
Level: Y: 1 Vp/p (0.7 V Luma + 0.3 V Sync.).
Cr, Cb: 0.7 Vp/p.
Impedance: 75 Ohm.
* Available on the BSD830 & BHD930 models only.
